51"/72" x 160" acra SGT51160, New #SMSGT51160
Machine Type:
LATHES
Manufacturer:
Acra
Model:
SGT51160
Capacity:
51"/72" x 160"
Condition:
New
Stock No:
#SMSGT51160
DETAILED SPECIFICATION
| Capacity | 51"/72" x 160" |
| Swing Over Bed | 51.57" |
| Swing Over Cross Slide | 39.37" |
| Distance Between Centers | 160" |
| Swing in Gap | 72.83" |
| Hole Thru Spindle | 6" |
| Spindle Nose | A2-11 |
| Spindle Speeds | 3 - 300 RPM |
| Width of Gap | 18.5" |
| Pitch of Leadscrew | 2 T.P.I |
| Inch Threads | 1/4 - 30 TPI (70 Kinds) |
| Metric Threads | 1 - 120 MM |
| Diametrical Threads | 1 - 120 D.P. |
| Module Pitches | 0.25 - 30 mm |
| Longitudinal Feeds | 0.085~10.08 mm/rev |
| Cross Feeds | 0.042 ~ 5.04 mm/rev |
| Spindle Taper | MT #6 |
| Cross Slide Travel | 25" |
| Compound Slide Travel | 16.5" |
| Tailstock Spindle Diameter | 4-7/8" |
| Tailstock Quill Travel | 13-3/8" |
| Width Of Bed | 26" |
| Horsepower | 30 H.P. |
| Voltage | 220/440V AC/3PH |
| Dimensions Machine (L x W x H) | 260" x 80" x 80" |
| WEIGHT | 25,000 LBS. |
Features
Center (M.T.#6)
4 Way Rapid Traverse
Steady Rest
Electromagnetic Spindle Brake
Tool Box & Tools
Anchor Bolts
Tool Post Wrench
Coolant System
Center Sleeve
Work Light
DISTRIBUTOR OF THE YEAR AWARD
* Temporary specifications subject to verification.
All quotations subject to prior sale.
New pricing is good only at time of invoice and must be paid Immediately to guarantee no price increases by the manufacturers.
